Take a Closer Look
Overview
Supports four global satellite navigation systems — BeiDou, GPS, Galileo, GLONASS, and 11-frequency satellite reception, providing real-time differential corrections to facilitate the aircraft in centimeter-level precision positioning. It also supports coordinated operations involving multiple drones and an IP65 protection rating.
Highlights
Supports: GPS: L1 C/A, L2, L5; BEIDOU: B1, B2, B3; GLONASS: F1, F2; Galileo: E1, E5A, E5B
Connect multiple drones to conduct coordinated operations
IP65 Ingress Protection
Connect multiple drones to conduct coordinated operations
IP65 Ingress Protection
In The Box
D-RTK 2 Body × 1
Extension Rod × 1
Charging Hub × 1
Intelligent Battery (WB37) × 2
Battery Cover × 1
USB-C Cable × 1
USB-C OTG Cable × 1
Hex Key × 1
Extension Rod × 1
Charging Hub × 1
Intelligent Battery (WB37) × 2
Battery Cover × 1
USB-C Cable × 1
USB-C OTG Cable × 1
Hex Key × 1
Specifications
Simultaneously receives:
GPS: L1 C/A, L2, L5
BeiDou: B1, B2, B3
GLONASS: F1, F2
Galileo: E1, E5A, E5B
Positioning Accuracy:
Single Point Horizontal: 1.5 m (RMS)
Vertical: 3.0 m (RMS)
Horizontal (RTK FIX): 1 cm+1 ppm (RMS)
Vertical (RTK FIX): 2 cm + 1 ppm (RMS)
1 ppm: For every 1 km increase in distance, the accuracy will be 1 mm less. For example, the horizontal accuracy is 1.1 cm when the receiving end is 1 km away from the base station.
IP65 Rating
Operating Temperature: -20° to 55° C (4° to 131° F )
GPS: L1 C/A, L2, L5
BeiDou: B1, B2, B3
GLONASS: F1, F2
Galileo: E1, E5A, E5B
Positioning Accuracy:
Single Point Horizontal: 1.5 m (RMS)
Vertical: 3.0 m (RMS)
Horizontal (RTK FIX): 1 cm+1 ppm (RMS)
Vertical (RTK FIX): 2 cm + 1 ppm (RMS)
1 ppm: For every 1 km increase in distance, the accuracy will be 1 mm less. For example, the horizontal accuracy is 1.1 cm when the receiving end is 1 km away from the base station.
IP65 Rating
Operating Temperature: -20° to 55° C (4° to 131° F )
Compatibility
Matrice 350 RTK
DJI Inspire 3
DJI Mavic 3E
DJI Mavic 3T Matrice 30 Series
Phantom 4 RTK
Matrice 300 RTK
DJI Mavic 3E
DJI Mavic 3T Matrice 30 Series
Phantom 4 RTK
Matrice 300 RTK
